4.4 Connecting sensors
￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
20
￭￭￭￭￭￭￭￭
899 Coulometer
1
Figure 12 Unscrewing the cover from the indicator electrode
2
Tighten the 6.2104.020 electrode cable to the indicator electrode.
2
6.2104.020
Figure 13 Screwing the electrode cable to the indicator electrode
Connecting the electrode cable to the coulometer
1
Plug the electrode plug into the Ind. socket of the coulometer.
Figure 14 Connecting an indicator electrode
