4.4 Connecting sensors
￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
18
￭￭￭￭￭￭￭￭
899 Coulometer
4.4 Connecting sensors
The measuring interface contains the following measuring inputs:
￭ Gen. for a generator electrode
￭ Ind. for a double Pt electrode
￭ Temp. for a temperature sensor of the Pt1000 type
CAUTION
Under all circumstances, avoid mixing up the electrode cable from the
indicator electrode with the one from the generator electrode. Mark
the screw heads of the cables accordingly.
4.4.1 Connecting a generator electrode
Screwing the electrode cable to the generator electrode
1
Unscrew the cover of the generator electrode.
1
Figure 9 Unscrewing the cover from the generator electrode
2
Tighten the 6.2104.120 electrode cable to the generator electrode.
