4 Installation
899 Coulometer
￭￭￭￭￭￭￭￭
19
Figure 10 Screwing the electrode cable to the generator electrode
Connecting the electrode cable to the coulometer
1
Plug the electrode plug into the Gen. socket of the coulometer.
Figure 11 Connecting a generator electrode
NOTE
The electrode cable is protected against accidental disconnection
of the cable by means of a pull-out protection. If you wish to pull
out the plug again, you first need to pull back the outer plug
sleeve.
4.4.2 Connecting an indicator electrode
Screwing the electrode cable to the indicator electrode
1
Unscrew the cover of the indicator electrode.
