2.3 Setting up the aspiration and reagent bottle
￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
22
￭￭￭￭￭￭￭￭
4
Cut off a piece (approx. 1 m) of the 6.1801.120 PVC tubing and con-
nect to the 6.1609.010 adsorber tube filled with molecular sieve.
Additional details can be found in the chapter "Filling the adsorber
tube" (see chapter 2.2.2, page 7).
5
Place the adsorber tube with the SGJ 14 standard ground-joint on
the bottle cap.
6
Secure the SGJ 14 standard ground-joint of the adsorber tube with
the 6.2023.020 SGJ clip.
7
Place the completely equipped 6.1602.105 bottle cap on a reagent
bottle from your chemicals manufacturer and screw it tightly.
Setting up the aspiration bottle
The aspiration bottle is used as a waste container and must be sealed
against leaks.
Metrohm offers suitable thread adapters for bottles with other threads
than GL 45.
