XP-GT/GTR Programming Manual
v4.00
Sensor Arm TZ
Enter Input No.[?]
(Min=01, Max=02)
Arming TZ: [FF]
√ - OK X - Cancel
5.1.5 View Sensor State
This menu lets users view the sensor state; whether connected or not connected.
To view the state of the sensors, please follow steps below:
1. Enter Configuration Menu.
2. Press 5 for Alarm Menu.
3. Press 1 for Input Setting.
4. Press 5 for View Sensor State. Screen as below will be shown. If the sensor
is not connected, [E] will be shown. If the sensor is connected to the alarm
panel, [N] will be shown. Press
√ to return to Input Setting.
View Sensor State
Current Sensor State
S[E] S[E] S[E] S[E]
√ - OK X - Cancel
5.2 Output Setting
5.2.1 Output On/Off
This menu lets users toggle the selected output to be on or off.
To toggle the output on or off, please follow steps below:
1. Enter Configuration Menu.
2. Press 5 for Alarm Menu.
3. Press 2 for Output Setting.
4. Press 1 for Output On/Off. Screen as below will be shown. Enter from 1 to 4
to select the alarm output. Press
↑ or ↓ to toggle the output ON or OFF. Press
√ to save changes.
Output On/Off
Switch Output No.[?]
(Min=01, Max=04)
Status : [OFF]
√ - OK X – Cancel
