Microhard Systems P900 - P900 Technical Specifications

© Microhard Systems Inc. Confidential 11
1.0 Overview
1.2 Pico Series P900 Specifications
Electrical/General
Frequency: 902 - 928 MHz
Spreading Method: Frequency Hopping
Band Segments: Selectable via Freq. Zones
Error Detection: 32 bits of CRC, ARQ
Data Encryption: 128, 196 or 256-bit AES Encryption (Requires export
(Optional) permit outside US and Canada.)
Range: 40 miles (60km)
Output Power: 100mW to 1W (20-30dBm)
Sensitivity:
Serial Baud Rate: Up to 230.4 kbps asynchronous
Link Rate: Up to 276 kbps
Environmental
Operation Temperature: -40
o
F(-40
o
C) to 185
o
F(85
o
C)
Humidity: 5% to 95% non-condensing
Mechanical
Dimensions: Approx: 1.05” (26.5mm) X 1.3” (33mm) X 0.13”(3.5mm)
Weight: Approx: 5 grams
Connectors: Antenna: UFL
Data: 80 Pin/Pad SMT
Caution: Using a power
supply that does not
provide proper voltage or
current may damage the
modem.
Link Rate 10
-6
BER 10
-3
BER
57.6 kbps -111 dBm -114 dBm
115.2 kbps -110 dBm -113 dBm
172 kbps -108 dBm -111 dBm
230 kbps -107 dBm -110 dBm
276 kbps -106 dBm -109 dBm
