Microhard Systems P900 - Recommended Solder Paste Pattern; OEM Connectors

© Microhard Systems Inc. Confidential 15
19.91
30.0734.39
28.04
2.18
2.0 Hardware Description
2.1.2 Recommended Solder Paste Pattern
Drawing 2-3: P900 Recommended Solder Paste
Units: millimeters
Detail
(C)
Detail
(C)
2.1.3 OEM Connectors
Antenna
All P900 OEM Modules use an UFL connector for the antenna connection.
Data
The interface to the P900 OEM module is a tight integration using 80 pad SMT connections.
Detail
(D)
Detail
(D)
1.88
2.55
1.27
1.03
0.86
3.50
3.38
4.12
1.00
