2.0 Hardware Description
2.3 Minimum Connection Requirements
Drawing 2-6: P900 Minimum Connection Block Diagram
P900
Antenna
1 17 25 26 39 40 41 65 66 67 78 79 80
GND Pins
62 63 64
UFL
V
CC
V
DD
29 Serial TxD
28 Serial RxD
3.3V
Optional
Driver
RS-232
