4.16 System Adjustment Window
4.16.3 General
System Adjust is for positioning to the right energy location of
the known peaks in KeV using Reference Standard which is
contained Cu and Sn.
Load Reference standard on the stage and adjust XY & focus.
Click 'START' button to adjust.
System will turn on X-Ray several times and adjust the value
of the Offset and Gain automatically to find proper position for Cu and Sn
peaks.
4.16.4 Concept of the system adjust
Reference Standard contains two elements, Cu and Sn. The energy of
the Cu is 8.048Kev and Sn is 25.27 KeV.
A good example of the System Adjust likes the following figure.
To display Peak Information, place cursor on the Spectrum Screen then
press Alt+P simultaneously.
