XRF-2000 Series Operating Manual
8
liquid or thin film form; or even be a few layers of elements plated
on a thick base substrate. In most cases, samples are analyzed
with minimal preparations.
1.3 TYPICAL SPECIFICATIONS
Input Power
115/220 VAC, 50/60Hz, 150W (maximum) Typically 220VAC 0.5A
Power Cable
The power cable will be supplied by the local MP representative to meet
IEC 224 or IEC 245 standards.
The inner wire diameter should be at least 0.75mm.
Fuse
On the Main Power: 2A
Power On/Off Switch
Once the AC input cable is connected from the system to the wall,
system power up and shut-down should be done using the On/Off switch
on the front right side of the system.
Connect to PC
Only one connection by USB Cable
XRF-2000
USB Cable
XRF-2000Series PC
