Midas M32 User Manual

100 M32 - Digital Console User Manual 101
Stereo Combinator / Dual Combinator
The Combinator is an amazing 5-band compressor that emulates famous broadcasting and mastering compressors. A high-
ly complex processor, the Combinator utilises automatic parameter control that produces stunning and “inaudible” results.
Makeup-gain for each frequency band will automatically be adjusted by the Spectral Balance Control (SBC) function, to
maintain a balanced audio spectrum.
Fair Comp / M/S Fair Comp / Dual Fair Comp
The Fairchild 670 tube compressor not only achieves record bids in high-end vintage gear auctions, it also delivers some
of the nest colourations in compressor history. Two small trim VRs preset the control side chain action, a six-step switch
determines the timing, and the two large Input and Threshold knobs adjust the levels. Our FAIR COMPRESSOR model is true
to the original signal path, and conveniently provides models for dual, stereo-linked or M/S operation. Inspired by Fairchild
670.
Provisional
www.theaudiospecialists.eu

Midas M32 Specifications

General

Channels	40
Outputs	16 x XLR
Faders	25
Sample Rate	48 khz
Type	Digital
Talkback	1 x XLR
A/D Resolution	24-bit
Dynamic Processing	Yes
Control Surface	Yes
Effects	8 stereo effects processors
EQ	4-band
Display	7" TFT
Connectivity	Ethernet, USB
Inputs - Other	6 x Aux
Outputs - Main	2 x XLR
Outputs - Other	6 Aux, 2 FX
Data I/O	Ethernet, AES50
USB	1 x Type B
Computer Connectivity	USB, Ethernet
I/O Expansion Slots	1 x Expansion Slot
MIDI I/O	In/Out
Word Clock	In/Out
Depth	490 mm
Weight	15 kg
USB Audio Interface	32-in/32-out
Network Audio	AES50
Dimensions	760 x 168 x 490 mm
Inputs	32 x XLR/TRS combo
