Midmark VetPro - Page 102

VetPro DC Installation/Service Manual, 00-02-1606, Revision R01
99
Figure 78
6. Remove the two Allen head screws that secure the two ground wires to
the yoke. Take note of the position of each ground wire.
Figure 79
7. Remove the end cap from the side of the tubehead.
Figure 80
8. Remove the small Phillips head screw that holds the cable restraint.
3mm screws (2x)
