VetPro DC Installation/Service Manual, 00-02-1606, Revision R01
101
12. Secure the scissor arm with the provided cable tie and foam separator
before removing both spanner rings.
Do not remove the tubehead until this step has been
completed. The spring tension is adjusted to include its weight
so the articulating arm will spring open and can cause serious
injury if it is not secured.
13. Assemble the spanner wrench by threading the two leverage arms into
the base of the spanner wrench.
14. Align the three pins on the spanner tool with the alignment holes in the
brass spanner nut.
