Miller Continuum - 5-2. Feeder Location; 5-3. Mounting Hole Location

OM-266409 Page 14
1 Lifting Eye
When a feeder is installed on top of
power source, lift eye is inserted
through slot in feeder base.
5-2. Feeder Location
1
Loc_contfeeder 2015-07
. Holes are designed for 3/8 in.
hex head bolts.
5-3. Mounting Hole Location
Ref. 266 419-B
2.8 in.
3.975 in.
7.95 in.
(71 mm)
2.8 in.
(71 mm)
2.8 in.
(71 mm)
2.8 in.
(71 mm)
(202 mm)
(101 mm)
