Page 60 Accumass BW500 PL-565
Parameters
P015 Speed Constant
This value is used with the speed sensor frequency, to calculate the actual belt
speed. (f=0.0000)
Entry:
If speed input is wired for constant speed (terminals 17/18 jumpered), value
defaults to 'jumpered'.
If the speed input is connected to a speed sensor, press . P015 automatically
jumps to P690. Refer to P690 on page 80 for speed constant entry.
P016 Belt Length
The length of the conveyor belt (one belt revolution). (f=0.000)
Length units are:
feet: if the imperial system of measurement has been selected, P004 = 1
metres: if the metric system of measurement has been selected, P004 = 2
Enter the belt length
P017 Test Load
The load to be referenced when performing a span. (f=0.00)
Load units are:
lb/ft: if the imperial system of measurement has been selected,P004 = 1
kg/m: if the metric system of measurement has been selected,P004 = 2
The display indicates the test reference as selected by P002; either: ‘weight’, ‘chain’
or ‘ECal’ and the multispan number MS, 1-8.
Enter the test load value
In the case of ECal, pressing enter at P017 invokes P693 for data entry. ECal sets
the value for P017 at 100% of design load (P952).
P018 Speed Adjust
This parameter allows adjustment to the speed constant (P015). Initially, this
parameter displays the dynamic speed of the belt. If the displayed speed is not equal
to the actual speed, enter the actual belt speed. (f=0.00)
For speed sensor applications, the value of P015 is automatically adjusted.
For constant speed (terminals 17/18 jumpered) the value of P014 is automatically
adjusted.
