7.1.1. DESCRIPTION OF THE MACHINE PARAMETERS
Parameter
Description
Coveyor delayed starting
If Cycle speeding up is set on ON, distance the table must run before the
conveyor starts moving
Conveyor encoder coefficient
Number of encoder pulses per unit of movement
Critical speed #1
Wire cutting speed below which the maximum delay in sending, the stop command
is applied
Critical speed #2
Wire cutting speed above which the stop command is sent without applying any
delay
Enable HMI updating
- ON: the touch screen panel updating procedure is enabled and the program
backup or restore procedure are disabled
- OFF: the touch screen panel updating procedure is disabled and the program
backup or restore procedure are enabled
Language
It allows to change the system language
Lifting encoder coefficient
Number of encoder pulses per unit of movement
Lifting speed
Speed used for table positioning
Low table distance
Lifting system maximum run
Max. wire-cut delayed stop
Maximum waiting time before the wire cutting system stop command is sent
Maximum encoder pulses
Maximum number of encoder pulses per unit of time
Maximum table speed
Maximum speed used for table in movements
Maximum tray speed
Maximum speed used for tray in movements
Minimum table distance
Minimum settable value of the Table distance parameter
Minimum table speed
Minimum speed used for table in movements
Minimum tray speed
Minimum speed used for tray in movements
Product detachment
If enabled, table lowering distance at end of dosing
Pump head offset
Distance (in height) between the pump type head and the machine zero
Pump head offset (backward)
Distance between the tray edge and the centre of the mould at tray detecting
when the roller type dosing unit is being used and the running direction is set
at Backward
Pump head offset (forward)
Distance between the tray edge and the centre of the mould at tray detecting
when the roller type dosing unit is being used and the running direction is set
at Forward
Roller head offset
Distance (in height) between the roller type head and the machine zero
Roller head offset (backward)
Distance between the tray edge and the centre of the mould at tray detecting
when the pump type dosing unit is being used and the running direction is set
at Backward
Roller head offset (forward)
Distance between the tray edge and the centre of the mould at tray detecting
when the pump type dosing unit is being used and the running direction is set
at Forward
Scrape pause
Waiting time between the end of the dosing phase and the Scrape movement
Scrape speed
Belt conveyor speed during the Scrape movement
Table inertia
Table stopping space with no braking
Timeout password
It allows to enable, disable or time the user password
Tray feed speed
Speed used for tray positioning
Tray inertia
Belt conveyor stopping space with no braking
Tray loading speed
Speed of the belt conveyor while waiting for the tray at work starting
Tray stopping space
The machine ends production if the entry of a new tray is not detected within the
set distance
