Mindray DC-40 User Manual

Measurement 8-5
Parameter Value Range Error
Velocity (CW
mode)
10-300cm/s (for P4-
2)
When angle≤60º, ≤5%. (not including pencil
probe)
Table 4 Doppler Velocity Measurements
Parameter Value Range
Velocity (PW mode)
Min.≤0.10cm/s, Max.≥462cm/s
Velocity (CW mode)
Min.≤0.06cm/s, Max.≥3080m/s
Velocity (Color mode)
Min.≤1cm/s, Max..≥239.5cm/s
NOTE: Within the selected field range, the measurement accuracy is ensured within
the range mentioned above. The accuracy specifications are performance in
the worst conditions, or based on the real test for the system, regardless of
acoustic speed error.

Mindray DC-40 Specifications

General

Touch Screen	Yes
Hard Drive	500 GB
3D/4D Imaging	Yes
Storage Temperature	-20°C to +60°C
Operating Temperature	+10°C to +40°C
Atmospheric Pressure	700 hPa to 1060 hPa
Imaging Modes	B, M, Color Doppler, Power Doppler
Probes	Convex, Linear, Phased Array
Connectivity	DICOM, USB, Ethernet
Power Supply	100-240V AC, 50/60Hz
Display	15-inch color LCD
