Mindray DC-40 User Manual

13-4 Probes and Biopsy
13.1.2 Orientation of the Ultrasound Image and the
Probe Head
The orientation of the ultrasound image and the probe are shown as below. The “Mark”
side of the ultrasound image on the monitor corresponds to the mark side of the probe.
Check the orientation before the examination (Here takes linear probe as an example).
13.1.3 Procedures for Operating
This section describes general procedures for operating the probe. The proper clinical
technique to be used for operating the probe should be selected on the basis of
specialized training and clinical experience.
Mark
Orientation mark

Mindray DC-40 Specifications

General

Touch Screen	Yes
Hard Drive	500 GB
3D/4D Imaging	Yes
Storage Temperature	-20°C to +60°C
Operating Temperature	+10°C to +40°C
Atmospheric Pressure	700 hPa to 1060 hPa
Imaging Modes	B, M, Color Doppler, Power Doppler
Probes	Convex, Linear, Phased Array
Connectivity	DICOM, USB, Ethernet
Power Supply	100-240V AC, 50/60Hz
Display	15-inch color LCD
