Ultrasound Gel Warmer E-1
Appendix E Ultrasound Gel
Warmer
Ultrasound gel warmer is a system option used for heating the ultrasound gel.
E.1 Overview
As shown in the figure above, the warmer is installed on the left side of the control panel,
where the ultrasound gel is positioned.
E.2 Structure
No. Name Function
1. Ultrasound gel box Used for positioning the ultrasound gel.
2. Warming control switch
Set the gel warmer to the temperature of 37/40, or turn
off.
3. Status indicator
Working normally: green.
Failure: blink in orange.
4. Power cable Connects to the power socket under the control panel.
