Image Optimization 5-3
Check image parameter level and other settings:
z Click [Show Parameter] to check levels of different image parameters. Click [OK]
to save the current image values for the current exam mode of the particular
probe.
This function is not available under dual-probe frozen mode.
5.2 B Mode Image Optimization
B mode is the basic imaging mode that displays real-time images of anatomical tissues
and organs.
5.2.1 Basic Procedures for B Mode Imaging
1. Enter the patient information. Select an appropriate probe and exam mode.
2. Press <B> on the control panel to enter B mode.
3. Adjust the parameters to optimize the image.
4. Perform other operations (e.g., measurement and calculation) if necessary.
Press <B> on the control panel to return to B mode at any time.
5.2.2 B Mode Parameters
In B mode scanning, the image parameter area in the top-right corner of the screen
displays the real-time parameter values as follows:
Parameter F D G FR DR iClear iBeam iTouch Zoom
Meaning Frequency Depth Gain
Frame
Rate
Dynamic
Range
Display when the function is turned
on.
