Mindray DC-40 User Manual

Image Optimization 5-21
5.6.2 PW/CW Mode Image Parameters
In PW/CW mode scanning, the image parameter area in the top-right corner of the
screen displays the real-time parameter values as follows:
PW Parameter F G PRF WF SVD SV Angle
Meaning Frequency Gain PRF Wall
Filter
SV
Position
SV Size Angle
CW Parameter F G PRF WF SVD Angle
Meaning Frequency Gain PRF Wall Filter SV Position Angle
 During PW/CW mode imaging, the image optimizing menus for B mode and PW/CW
mode are displayed on the touch screen at the same time. If Color mode (Power
mode) is also working, menus for certain modes will be displayed on the touch
screen synchronously, and you can switch between them by clicking the mode tabs.
 When you adjust the depth of the B mode image, related changes will occur in the
PW/CW mode image as well.
 Most of the parameters are the same for the PW mode and CW modes, so
parameters of both are combined together to be introduced here.
Only phased probes support CW mode.

Mindray DC-40 Specifications

General

Touch Screen	Yes
Hard Drive	500 GB
3D/4D Imaging	Yes
Storage Temperature	-20°C to +60°C
Operating Temperature	+10°C to +40°C
Atmospheric Pressure	700 hPa to 1060 hPa
Imaging Modes	B, M, Color Doppler, Power Doppler
Probes	Convex, Linear, Phased Array
Connectivity	DICOM, USB, Ethernet
Power Supply	100-240V AC, 50/60Hz
Display	15-inch color LCD
