Mindray DC-40 User Manual

System Overview 2-3
2.4.4 Size and Weights
 External dimensions:
z 812mm (L)X600mm (W)X1331(1515)mm (H)
 Net weight: 130.87Kg (without the battery)
2.5 System Configuration
2.5.1 Standard Configuration
 Main unit
 Accessories
z Operator's manuals
z Ultrasound gel
z Dust-proof cover
z Probe ports dust-proof cover
z Tray assembly
z Left bracket for the intra-cavity probe
z Right bracket for the intra-cavity probe
z Probe holder
z Probe holder for pencil probe
z Cables
z Grounding cable
z Multilingual controls overlay
2.5.2 Probes Available
No. Probe Model Intended Use Region Applied
1.
3C5A Gynecology, obstetrics, abdominal,
vascular, musculoskeletal, pediatric
Body surface
2.
7L4A Small parts, vascular, pediatric,
musculo-skeletal, abdominal, cephalic,
orthopedic
Body surface
3. 6C2
Small parts, vascular, pediatric,
musculo-skeletal, abdominal, cephalic,
cardiac, nerve
Body surface
4. L14-6
Small parts, vascular, pediatric,
musculo-skeletal, abdominal, cephalic
Body surface
5. V10-4B/V10-4 Gynecology, obstetrics, urology Transvaginal
6. 7L5
Small parts, vascular, pediatric,
musculo-skeletal, abdominal, cephalic,
orthopedic
Body surface
7. L7-3
Small parts, vascular, pediatric,
musculo-skeletal, abdominal, cephalic,
orthopedic
Body surface

Mindray DC-40 Specifications

General

Touch Screen	Yes
Hard Drive	500 GB
3D/4D Imaging	Yes
Storage Temperature	-20°C to +60°C
Operating Temperature	+10°C to +40°C
Atmospheric Pressure	700 hPa to 1060 hPa
Imaging Modes	B, M, Color Doppler, Power Doppler
Probes	Convex, Linear, Phased Array
Connectivity	DICOM, USB, Ethernet
Power Supply	100-240V AC, 50/60Hz
Display	15-inch color LCD
