System Overview 2-15
Common functional keys
No. Key Function
1. Enter
Confirm the entered data, or move the cursor to the top of
the next row of the text or input field.
2. Esc Cancel the operation or exit.
3. Tab Jump to the next operable item.
4. Back space Insert a space.
5. Caps Lock Switch between upper/lowercase.
6. Home
Activate the Home function: return to start position of the
comment.
7. Delete Text Delete all comments on the screen.
8. Direction-control keys
Move the cursor one letter each time, or, select the
surrounding objects in the selectable area.
9. Del Delete the character after the cursor
10. Back Space Delete the character before the cursor
Functions of the F1 to F12 keys
No. Key Function
1 F1 Help Open or close the accompanying help documents.
2 F2 iStation Enter or exit the Patient Info system.
3 F3~F6 User-defined keys, the functions of which can be preset.
4 F7 QSave Save the current image parameters quickly.
5 F8 iZoom Enter/exit full-screen zoom status.
6 F9 DVR Reserved, enter/exit DVR mode.
7 F10 Setup Enter/exit Setup.
8 F11 Biopsy Display/hide the guide line.
9 F12 User-defined keys, the functions of which can be preset.
Functions of key combinations
The system supports multi-language input using key combinations. Key combinations
include [Shift], [Alt Gr], [Ctrl], [Fn] and some alphabet keys. For details about switching
the system to multi-language, see “12.1.1 Region” for details.
z <Shift> key
<Shift> + key: enter the top left letter on the key.
For the alphabet keys (<A>~<Z>), press <Shift> + key to enter the current letter in a
different case.
z [Alt Gr] key
Combined with other letter keys, [Alt Gr] can be used for entering other languages.
Press [Alt Gr] and a letter key simultaneously. The letter in the top-right corner of the
key is entered.
z [Ctrl] key combined keys
On the iStation or Review screen, use <Ctrl> and <Set> to select more than one
patient or more than one image.
z [Fn] key
