Mindray DC-40 User Manual

System Preparation 3-15
1. Printer room window 2. Printer 3. Room cover
z
Color analog video printer: use the I/O panel at the rear side of the machine to
connect the printer, as shown in the following figure:
4. Load a paper roll, and turn on the system and printer.
5. Modify print service:
z Add a print service:
(1) Open the [Setup]Æ[Print Preset]Æ[Print Service].
(2) Click [Add Service] to enter the page.
(3) Select the service type and enter the service name manually.
(4) Click [OK] to return to the Printer Service page.
(5) Select the printer model, and then you can set the properties in the Property box.
(6) Click [OK] to complete the setting.
z Modify print service:
(1) Select an existed printer service in the list.
(2) Select the printer model, and then you can set the properties in the Property box.
(3) Click [OK] to complete the setting.
2
3
1
Connect to
S-Video out
cable
Connect the
remote cable
of the printer

Mindray DC-40 Specifications

General

Touch Screen	Yes
Hard Drive	500 GB
3D/4D Imaging	Yes
Storage Temperature	-20°C to +60°C
Operating Temperature	+10°C to +40°C
Atmospheric Pressure	700 hPa to 1060 hPa
Imaging Modes	B, M, Color Doppler, Power Doppler
Probes	Convex, Linear, Phased Array
Connectivity	DICOM, USB, Ethernet
Power Supply	100-240V AC, 50/60Hz
Display	15-inch color LCD
