System Preparation 3-21
Image manage area
z Page up/down: when there are more than one page images have been stored,
you can turn to the next or preview page by
or respectively.
z Delete: select a thumbnail image, and click to delete it.
z Send to: select a thumbnail image, and click to send it to external devices.
Soft Menu area
The monitor's soft menu area displays the items that simultaneously appear at the
bottom of the touch screen.
System status area
This area displays the relevant system icons, such as USB memory device, printer,
network connection, and current system time, etc.
None-fixing Area
Areas illustrated here are position-changeable; you can move them by the trackball
within a certain area on the monitor.
z Result window
The measurement result window displays the results of recently performed
measurements.
To move the result window:
a) Place the cursor on the title of result window (you can see the cursor
changes into
).
b) Press <Set> and move the trackball, the window moves together with the
cursor.
c) Move the cursor to the target position, press <Set> again to anchor the
result window in the target position.
z Comment area
For details, please refer to “9 Comments and Body Marks”.
z Body mark area
For details, please refer to “9 Comments and Body Marks”.
