Specifications 2-5
2.1.2.3 Physio Panel
No.
Name
Function
<1> USB port Connects USB device.
<2> Pencil probe port Used for connecting a pencil probe.
<3> MIC port Used for connecting a microphone.
<4>
ECG lead signal input
port/external ECG
signal input port
Connects to ECG leads to directly obtain the patient's ECG
signals.
Connects the signal output port of an external ECG monitoring
device.
<5> PCG signal input port Reserved.
<6> Reserved port Reserved.

Mindray DC-70 Exp Specifications

General

Touch Screen Size	10.4 inch
Probe Ports	4
Power Supply	100-240V AC, 50/60Hz
Connectivity	DICOM, USB, Ethernet
Applications	Abdominal, Cardiac, OB/GYN, Vascular
Weight	85 kg
Doppler Modes	PW, CW, Color Doppler, Power Doppler
Imaging Modes	2D, M-Mode, 4D
Storage	500GB hard drive
