Mindray DC-70 Exp User Manual

2-6 Specifications
2.1.2.4 Control Panel
No. Name Description
<1> /
Power button
Press the button to turn on the system, the system enters the work
status and the indicator becomes green.
<2> Volume Adjust the volume.
<3> /
Adjust the corresponding functions on the touch screen.
<4> /
<5> /
<6>
/
<7> /
<8> TGC Slide to adjust the depth gain.
<9> Patient Enter/exit Patient Info screen.
<10> Probe Switch probe and exam mode.
<11> Review Review the stored images.
<12> Report Open/close the exam report.

Mindray DC-70 Exp Specifications

General

Touch Screen Size	10.4 inch
Probe Ports	4
Power Supply	100-240V AC, 50/60Hz
Connectivity	DICOM, USB, Ethernet
Applications	Abdominal, Cardiac, OB/GYN, Vascular
Weight	85 kg
Doppler Modes	PW, CW, Color Doppler, Power Doppler
Imaging Modes	2D, M-Mode, 4D
Storage	500GB hard drive
