Mindray DC-80A Service Manual

2-2 Specifications
No.
Name
Function
8.
Keyboard
Used for typing characters or entering some functions.
9.
Main control panel
Operator-system interface or control.
10.
Control panel adjusting
lever
Used for lifting or swiveling the control panel.
11.
USB_MIC port
USB/MIC port
12.
Hanger
/
13.
Intracavitary probe
holder
Used for fixing the intracavitary probe.
14.
Ultrasound gel
holder/gel warmer
Used for placing the ultrasound gel or installing the gel warmer.
15.
Physio panel
Used for connecting the ECG leads and external ECG device.
16.
Compartment
Used for positioning the B/W video printer.
17.
Probe port
Sockets connecting transducers and the main unit.
18.
Caster
Used for securing or moving the system.
19.
Monitor supporting arm
Supports the monitor, for adjusting the height and position of the
monitor.
20.
Rear handle
Used for pushing and moving the system.
21.
Supporting arm locking
lever
Used for locking/unlocking the supporting arm
22.
Cooling vent
/
23.
I/O Panel
Interface panel used for inputting and outputting signals.
24.
Caster brake
Used for locking/unlocking the caster
25.
Power supply panel
Electrical port panel.
26.
DVD-RW
DVD-RW drive.
