Specifications 2-5
2.1.2.3 Physio Panel
No.
Name
Function
<1>
USB port
Connects USB device.
<2>
Pencil probe port
Used for connecting a pencil probe.
<3>
MIC port
Used for connecting a microphone.
<4>
ECG lead signal input
port/external ECG
signal input port
Connects to ECG leads to directly obtain the patient's ECG
signals.
Connects the signal output port of an external ECG monitoring
device.
<5>
PCG signal input port
Reserved.
<6>
Reserved port
Reserved.
