5-54 Image Optimization
Display format setting.
Image reset.
Entering/Exiting Image Viewing
Exit
To return to 3D/4D image acquisition preparation status, you can,
Click [Return] in the soft menu,
Press <Freeze>, <Update> or <Esc>.
B Mode Parameters Adjustment
Use the left/ right keys of soft menu controls <4> to switch to the B menu, and adjust the
image effect by B image parameters.
Image Rendering Parameters
In image viewing status, you can render the image by adjusting the parameters.
Render setting parameters description:
Parameter Description
Render
Gray/Inversion
Surface
Function: set Surface as 3D image rendering mode.
This is helpful for surface imaging, such as fetus
face/hand or foot.
Tips: you may have to adjust the threshold to obtain a
clear body boundary.
Max
Function: set Max as 3D image rendering mode, displays
the maximum intensity of gray values in the ROI.
This is helpful for viewing bony structures.
Min
Function: set Min as 3D image rendering mode, displays
the minimum number of gray values in the ROI.
This is helpful for viewing vessels and hollow structures.
X-ray
Function: set X-ray as 3D image rendering mode.
Displays the average value of all gray values in the ROI.
X Ray: used for imaging tissues with different structure
inside or tissues with tumor.
The above four rendering manners can be applied to both gray and
inversion modes.
Where, inversion is to inverse the grayscale of the image, so as to
enhance observation for low-echo region, applicable for vessel, cyst
and etc.
When the function is turned on, the rendering mode parameters
change into the corresponding inverse parameters.
Threshold
Function: to set the threshold for 3D image rendering. 3D image is
rendered using the signal between the high and low thresholds.
Range: 0%-100%, in increments of 1%.
Only used in surface imaging.
