Mindray M7 User Manual

Image Optimization 5-55
Parameter Description
Transparency
Function: to set the transparency value for 3D image rendering.
Range: 0%-100%, in increments of 5%.
The higher the number, the more transparent the gray scale
information.
Only used in surface imaging.
Smooth
Function: to set the smoothness of 3D image.
Selection: 0-20. 0 refers to no smooth effect, 0-20 present 21 effects in
incremental order.
Tips: insufficient smoothness can result in a fuzzy image; however,
over smoothness will lead to image distortion.
Brightness
Function: to set the brightness of 3D image.
Range: 0%-100%, in increments of 2%. 0% presents the minimum
brightness, while 100% the maximum.
Contrast
Function: to set the contrast of 3D image.
Range: 0%-100%, in increments of 2%.
MPR Line
Function: using the lines to show the position information of the other
sections on a section image or 3D image.
Selection: Entire, Partial, Off. Entire means to display the whole line
crossing the section image. Partial means to display part of the line at
both ends of the MPR line.
Colorize/Colorize
Map
Switch on/off colorize map, selection: Off, 1-5.
Quick Rot.
To quick rotation the 3D image.
Selection: 0°, 90°, 180°, 270°.
Reset Ori To reset the volume rotation, shifting and zooming to original status.
Reset All To reset volume to original orientation and original parameters.
Display Format
Image display format: click [Display Format] in the soft menu to set the image display
format, each adjustment cycles you to the next setting. Here,
 Select [Single], the system displays one image, which can be a section image or a 3D
image.
 Select [Dual], system displays two images left and right. (The left one can be section
A, section B or section C image, and the right one is 3D image.)
Or directly press <Dual> on the control panel.
 Select [Quad], system displays four images. (The upper left one is section A image,
the lower left one is sectional C image, the upper right one is section B image, and the
lower right one is 3D image.)
Or directly press <Quad> on the control panel.
Adjust VOI
 Function
Adjusting the VOI box size and position is to select the volume data needed to
re-render the 3D image and improve the re-render effect.
