5-8 Checking Performance and Functions
M mode
In M mode scan, the image parameter area on the right side of the screen displays the
real-time parameter values as follows:
Parameter Item F D G V DR
Meaning Frequency Depth M Gain M Speed M Dynamic Range
Parameters that can be adjusted to optimize the M Mode image are indicated in the following.
Adjustment Parameter Item
Control panel and
soft menu
adjustment
Gain, TGC, Depth, Focus Position, Display Format, Line Correlation, Tint
Map, Scan Speed, Edge Enhance, Dynamic Range, Gray Map.
Color mode
In Color mode scan, the image parameter area on the right side of the screen displays the
real-time parameter values as follows:
Parameter
Item
F G WF PRF
Meaning
Gain
Filter
Repetition
Frequency
Parameters that can be adjusted to optimize the Color mode image are indicated in the
following.
Adjustment Parameter Item
Control panel and
soft menu adjustment
Gain, Depth, TGC, Steer, iTouch
Image Quality, Scan Density, Persistence, Smooth, Sensitivity, B/C Wide,
Velocity, Flow, Wall Filter, Steer, B/C dual live, Caliper, Color Map, Color
Priority, Baseline, HR Flow.
Power mode
In Power mode scan, the image parameter area on the right side of the screen displays the
real-time parameter values as follows:
Parameter
Item
F G WF PRF
Meaning
Frequency Power Gain Power Wall
Filter
Pulse Repetition
Frequency
Parameters that can be adjusted to optimize the Power mode image are indicated in the
following.
Adjustment Parameter Item
LGC
B image soft menu-[LGC].
Images corresponding to four groups of parameters are displayed
on the soft menu (from left to right).
Click [LGC1-5] to adjust the parameters. To each segment of
image area, the system offers 5 values to adjust the gain. The
gain increases with the value becoming bigger.
In addition, the system provides several preset parameters for
imaging.
Echo Boost
B image soft menu-[Echo
Boost].
[Echo Boost] is enabled when it is on in B mode.(Highlighted) the
system is in “Echo Boost” status.
