Analog
3.0dB
Preset 3
Phono preamp
Power amplifier
Powered
subwoofer
Loudspeakers
Computer
USB audio
Digital sources
Turntable
miniDSP
Flex
Figure 1. miniDSPFlex as preamp with subwoofer integration
Figure 2 illustrates a similar use of the miniDSPFlex as a digital preamp, but the output channels have instead been
congured to act as crossover for a pair of active 2-way speakers. Amplication can be via a multichannel power
amplier as shown, or a pair of stereo ampliers.
