Input Channels
Input 1
RMS-Meter
(dBFS)
-14.0
Gain (dB)
0
PEQ
MUTE
Mute channel
Edit parametric EQ settings
Channel label
Level meter
Channel gain
Current
RMS level
Channel label
Each input channel has a customizable label displayed at the top of the channel strip. This label also appears on the
routing matrix. To change the label, click on it, type a new label (up to 12 characters), and press the Enter key.
Current RMS level, Level meter
Displays the current signal level in real time. (The device must be connected and online to display signal levels.)
Channel gain
The gain of each input channel can be set to a value between ‑72dB and +12dB. (0 dB, the default, is unity gain or no
change in level.) To set the gain, click on the Gain value of that channel. The gain can be entered by moving the slider
or it can be entered numerically. The up and down arrows can be used to change the gain in 0.1dB increments.
PEQ
Click on this button to open the parametric EQ settings window for that input channel. There are ten parametric EQ
lters on each input channel. See Parametric EQ.
Mute
