Taps are allocated to each block according to the number of loaded taps. The miniDSPFlex can compute a total of
4096 taps. These can be distributed as you wish across the four output channels, with the limitation that each channel
must have 6 or more taps and can have no more than 2048 taps.
The decision on how many taps to allocate to each channel is up to you and should be determined after working with
an FIR lter design program.
Loading lters
File mode
In File Mode, a lter coecient le generated by an FIR lter design program is loaded. The coecient le must use
IEEE 754 single-precision binary oating-point format (https://en.wikipedia.org/wiki/Single-precision_oating-
point_format#IEEE_754_single-precision_binary_oating-point_format:_binary32) .
FILE MODE
MANUAL MODE
Aa
Usage by Channel
Input 1 1024
Input 2 1024
Available 2048
Total 4096
No file chosen. Please click Browse button to begin.
Note: There must be at least 6 taps, and no more than 2048 Taps.
BROWSE
To load coecients, click Browse, navigate to the le containing the lter coecients, and open it. The rst few
coecients will be displayed and the buttons will change:
BROWSE
UNLOAD FIR
APPLY
woofer-impulse-2048.bin Usage by Channel
Input 1 2048
Input 2 1024
Available 1024
Total 4096
Note: There must be at least 6 taps, and no more than 2048 Taps.
b0 = -8.680318615006399e-7
b1 = -8.120589995996852e-7
b2 = -7.801536980878154e-7
b3 = -7.81908681801724e-7
b4 = -8.072910304690595e-7
b5 = -8.364621066903055e-7
b6 = -8.545673040316615e-7
b7 = -8.593909797127708e-7
The displayed graph will also change to reect the response of the loaded le.
To accept the loaded lter, click APPLY.
