Analog
3.0dB
Preset 3
Phono preamp
Multichannel
power amplifier
Left speaker
Computer
USB audio
Digital sources
Turntable
miniDSP
Flex
Right speaker
Figure 2. miniDSPFlex as preamp and active crossover
In Figure 3, the miniDSPFlex has been used as an accessory in a home theater system, to manage multiple
subwoofers. Driven from the A/V receiver's subwoofer output, the miniDSPFlex can be used to independently adjust
gain, delay and parametric EQ of each subwoofer for optimum multi-sub performance.
Analog
3.0dB
Preset 3
Subwoofer output from AVR
Up to four independent subwoofers
A/V Receiver
miniDSP
Flex
Figure 3. miniDSPFlex for multi-sub management
