Page #65 background image
65
7.6 Power Supply Wiring
7.6.1 Main Power Supply Wiring
Wire the Power Supply as shown in Figure 23 and adhere to the following:
Ensure that the AC supply is disconnected before wiring the power to the panel.
Wire the AC power to the AC wiring terminals as shown in Figure 23 using the proper
wire gauge with 600 volt insulation and proper over current circuit protection that
complies with local codes.
For the FX-400 Power Supply Electrical Ratings, see Table 15 Power Supply Electrical
Ratings and for specifications, see 11.0 Appendix D - Specifications.
Table 15 Power Supply Electrical Ratings
Type Electrical Rating
Electrical Input Rating 120 VAC, 60 Hz, 1.81 A / 240 VAC, 50 Hz, 0.98 A
Attention: The main AC branch circuit connection for the Fire Alarm Control Unit
must provide a dedicated continuous power without any disconnect
devices.
Fire alarm systems must be installed in compliance with local codes
and standards and with the Authority Having Jurisdiction (AHJ).
!
