2 - 71
2 SYSTEM CONFIGURATION
2.5.8 Battery
This section describes the battery specifications and handling precautions used for the
Motion controller.
(1) Battery specifications
Model name
Item
Q6BAT Q7BAT
Classification Manganese dioxide lithium primary battery
Initial voltage [V] 3.0
Nominal current [mAh] 1800 5000
Storage life Shelf life of 5 years (at room temperature)
Lithium content [g] 0.57 1.52
Applications For memory data backup of the RAM built-in Motion controller
Exterior dimensions [mm(inch)] 16(0.63) 32(1.26) 24(0.94) 52(2.05)
• Transport guidelines
Products are packed in compliance with the transportation regulations prior to
shipment. When repacking any of the unpacked products for transportation,
make sure to observe the IATA Dangerous Goods Regulations, IMDG
(International Maritime Dangerous Goods) Code, and other local transportation
regulations.
For details, please consult the shipping carrier used.
