Mitsubishi Electric Q170MSCPU-S1 - Instructions for Mounting the Modules

4 - 3
4 INSTALLATION AND WIRING
4.1.2 Instructions for mounting the modules
When mounting the Motion controller, base unit to an enclosure or similar, fully
consider its operability, maintainability and environmental resistance.
(1) Fitting dimensions
(a) Motion controller
[Unit: mm (inch)]
38(1.50) 7(0.28)
USB
POWER
STOPRESET RUN
CN1
EXT.IO
24VDC
EJECT
OUT
FRONT
CARD
RS-232
MOD E
RUN
ERR.
USER
BAT.
BOOT
PULL
PERIPHERAL I/F
EMI
NC
EMI.COM
Q170MSCP U
MITSUBISHI
186(7.32)
154(6.06)
52(2.05)
7(0.28)
3-fixing screw (M5)
8
(0.31)
