4 - 4
4 INSTALLATION AND WIRING
(b) Base unit
1) Q52B, Q55B
IN
I/O0 I/O1 I/O2 I/O3 I/O4
OUT
Ws
2
W
Hs
2
H
Ws
1 Hs
1
4-fixing screw (M4 14)
2) Q63B, Q65B, Q68B, Q612B,
5-fixing screw (M4 14)
I/O7 I/O8 I/O9 I/O10 I/O11
IN OUT
POWER
I/O0 I/O1 I/O2 I/O3 I/O4 I/O5 I/O6
Ws2Ws1 Ws3
W
Hs
2
H
Hs
1
Q52B Q55B Q63B Q65B Q68B Q612B
W 106 (4.17) 189 (7.44) 189 (7.44) 245 (9.65) 328 (12.91) 439 (17.28)
Ws1 15.5 (0.61)
Ws2
83.5 ± 0.3
(3.29 ± 0.01)
167 ± 0.3
(6.57 ± 0.01)
167 ± 0.3
(6.57 ± 0.01)
(Ws
2 + Ws3)
222.5
(8.76 ± 0.01)
(Ws2 + Ws3)
190 ± 0.3
(7.48 ± 0.01)
190 ± 0.3
(7.48 ± 0.01)
Ws3 — —
116 ± 0.3
(4.57 ± 0.01)
227 ± 0.3
(8.93 ± 0.01)
H 98 (3.86)
Hs1 7 (0.28)
Hs2 80 ± 0.3 (3.15 ± 0.01)
[Unit: mm (inch)]
