2 - 45
2 SYSTEM CONFIGURATION
2.5.2 Power supply module
(1) Power supply module specifications
Item Q61P Q62P Q63P Q64PN
Base loading position Q series power supply module loading slot
Applicable base unit Q35DB, Q38DB, Q312DB, Q63B, Q65B, Q68B, Q612B
Input power supply
100 to 240VAC (+10%/-15%)
(85 to 264VAC)
24VDC (+30%/-35%)
(15.6 to 31.2VDC)
100 to 240VAC (+10%/-15%)
(85 to 264VAC)
Input frequency 50/60Hz ±5% —— 50/60Hz ±5%
Input voltage distortion factor 5% or less —— 5% or less
Max. input apparent power 130VA 105VA 45W 160VA
Inrush current
20A 8ms or less
(Note-4)
100A 1ms or less
(at 24VDC input)
20A 8ms or less
(Note-4)
Rated output
current
5VDC 6A 3A 6A 8.5A
24VDC —— 0.6A ——
External output voltage —— 24VDC±10% ——
Overcurrent
protection
(Note-1)
5VDC 6.6A or more 3.3A or more 6.6A or more 9.9A or more
24VDC —— 0.66A or more ——
Overvoltage
protection
(Note-2)
5VDC 5.5 to 6.5V
Efficiency 70% or more 65% or more 70% or more
Allowable momentary power
failure time
(Note-3)
20ms or less
10ms or less
(at 24VDC input)
20ms or less
Dielectric withstand voltage
Across inputs/LG and outputs/FG
2,830VAC rms/3 cycles (Altitude: 2000m
(6561.68ft.) )
500VAC across
primary and 5VDC
Across inputs/LG and
outputs/FG
2,830VAC rms/3 cycles
(Altitude: 2000m (6561.68ft.))
Insulation resistance
Across inputs and outputs (LG and FG
separated), across inputs and LG/FG, across
outputs and LG/FG 10M
or more by insulation
resistance tester (500VDC)
10M
or more by
insulation resistance
tester
Across inputs and outputs (LG
and FG separated), across
inputs and LG/FG, across
outputs and LG/FG 10M
or
more by insulation resistance
tester (500VDC)
Noise immunity
• By noise simulator of 1,500Vp-p noise voltage,
1
µ
s noise width and 25 to 60Hz noise
frequency
• Noise voltage IEC61000-4-4, 2kV
• By noise simulator of
500Vp-p noise
voltage, 1
µ
s noise
width and 25 to 60Hz
noise frequency
• By noise simulator of
1,500Vp-p noise voltage,
1
µ
s noise width and 25 to
60Hz noise frequency
• Noise voltage IEC61000-4-4,
2kV
Operation indicator LED indication (Normal: ON (Green), Error: OFF)
Fuse Built-in (Unchangeable by user)
Contact
output
section
Application
ERR
contact
Rated switching
voltage/current
24VDC, 0.5A
Minimum switching
load
5VDC, 1mA
Response time OFF to ON: 10ms or less. ON to OFF: 12ms or less.
Life time
Mechanical: 20 million times or more
Electrical: 100 thousand times at rated switching voltage/current or more
Surge suppressor None
Fuse None
Terminal screw size M3.5 screw
To Next Page
