APPENDIX 2.1 Sample data
An easy setting can be achieved for the parameter setting such as the automatic
refresh setting of Multiple CPU setting and I/O assignment setting by using the sample
data.
Creation of project using the sample data is suitable for the machine control in the
sequence program.
The sample data have two types (Motion CPU area, PLC CPU area).
(1) Overview
(a) Multiple CPU setting
An easy setting can be achieved for the automatic refresh setting of
positioning dedicated signal between the PLC CPU area and Motion CPU
area.
(b) I/O assignment setting
The main base of eight slots or equivalent is built into the Q170MSCPU.
All points of "empty slot" not used on the main base are set to "0" point by
the sample data.
(c) Device comment
The name of positioning dedicated signal can be used as the device
comment of the sequence program.
(2) How to use
The following methods to use the sample data are shown below.
• Divert the sample data.
• Overwrite the sample data to the created project.
(3) Setting description
Outline of overwrite sample data is shown table below.
Add the extension base units and each module according to the system.
Refer to this section (7) for details of the sample data.
CPU area Item Description
Programming
software package
Project name
Motion CPU
area
Base setting
• Extension base
Stage1 to Stage 7
MT Developer2
SV13: Q170MS_SV13_MT2
SV22: Q170MS_SV22_MT2
(Note-1)
Q170MS_SV22_AD_MT2
(Note-2)
Multiple CPU
setting
• Multiple CPU high speed transmission
area setting
• Automatic refresh setting of CPU No.1, 2
PLC CPU
area
I/O
assignment
• Base setting
No. of slots for the base unit used
• I/O assignment
Unit types, I/O points, I/O number
• Base mode setting
GX Works2
SV13: Q170MS_SV13_GX2
SV22: Q170MS_SV22_GX2
(Note-1)
Q170MS_SV22_AD_GX2
(Note-2)
PLC system Points occupied by empty slot
Multiple CPU
settings
• No. of PLC
• Multiple CPU high speed transmission
area setting
• Auto refresh setting of CPU No.1, 2
Device
comment
Set the name of positioning dedicated signal
to the comment of device.
(Note-1): Project for virtual mode switching method.
(Note-2): Project for advanced synchronous control method.
