APP - 12
APPENDICES
(b) When the sample data is overwritten to the created project.
1) Motion CPU area
END
START
Start-up MT Developer2.
Create the project.
Divert the following sample data
in the basic setting of System
setting.
Base setting
Multiple CPU setting
Sample data
(1) Save folder
64-bit version operating system:
C:\Program Files (x86)\MELSOFT\MTD2\Lang\en-US\SampleData\MT2
32-bit version operating system:
C:\Program Files\MELSOFT\MTD2\Lang\en-US\SampleData\MT2
(2) Project name
SV13: Q170MS_SV13_MT2
SV22: Q170MS_SV22_MT2
Q170MS_SV22_AD_MT2
(Note-2)
(Note-1)
(Note-1): Project for virtual mode switching method.
(Note-2): Project for advanced synchronous control method.
2) PLC CPU area
Sample data
(1) Save folder
64-bit version operating system:
C:\Program Files (x86)\MELSOFT\MTD2\Lang\en-US\SampleData\GX2
32-bit version operating system:
C:\Program Files\MELSOFT\MTD2\Lang\en-US\SampleData\GX2
(2) Project name
SV13: Q170MS_SV13_GX2
SV22: Q170MS_SV22_GX2
Q170MS_SV22_AD_GX2
(3) Diversion file
"COMMENT" of device comment
(Note-2)
(Note-1)
(Note-1): Project for virtual mode switching method.
(Note-2): Project for advanced synchronous control method.
START
Start-up GX Works2.
Create the project.
END
Divert the following sample data
in the Multiple CPU settings or I/O
assignment of PLC parameter.
I/O assignment
PLC system
Multiple CPU settings
Divert the following sample data
by making a copy of project.
Device comment
POINT
The existing data is overwritten and erased by diverting the sample data to the
created project.
