APP - 46
APPENDICES
(5) Cable connector for serial absolute synchronous encoder
(3M Japan Limited make (SCR type))
Type Plug: 36210-0100PL
Shell: 36310-3200-008
[Unit: mm (inch)]
22.7(0.89) 11
34.8(1.37)
22.4(0.88)
10
8
39.6(1.56)
(0.39)
(0.31)
(0.43)
