2-36
2Unpacking to installation
Fig. 2-27 ： AXMC terminal connector
Fig. 2-28 ： AXMC terminal connector
30cm以内
フェライトコア
2回通し
CNUSR2コネクタ
* Connects with CNUSR2 connector with
soldering. Refer to Page 18 "Fig. 2-11:
Method of wiring for external emergency
stop connection (CR750 controller
(CNUSR2))".
＜ CR750 controller ＞
CNUSR2 connector
Within 30cm
Ferrite core
Pass twice
30cm以内
フェライトコア
2回通し
CNUSR2コネクタ
* The CNUSR2 connector is connected
by soldering. Refer to Page 20 "Fig. 2-
13: Method of wiring for external
emergency stop connection (CR751
controller (CNUSR1/2))".
＜ CR751 controller ＞
Ferrite core
Pass twice
CNUSR2 connector
Within 30cm
