MELSEC-Q
2 SYSTEM CONFIGURATION
2.2 Component list
A positioning system using the QD70 consists of the following components.
No. Product Type Remarks
1 Positioning module
QD70P4
QD70P8
QD70P
No. of control axes
Open collector output typeP
GX Developer SW D5C-GPPW-E
2
GX Configurator-PT SW
D5C-QPTU-E
For details, refer to the GX Developer Operating Manual and
"CHAPTER 6 UTILITY PACKAGE (GX Configurator-PT)".
3 Personal computer
DOS/V personal
computer
(User-prepared)
Refer to the GX Developer Operating Manual for details.
4 RS-232 cable QC30R2
(User-prepared)
RS-232 cable for connection of the CPU module and DOS/V personal
computer.
Refer to the GX Developer Operating Manual for details.
5 USB cable –
(User-prepared)
USB cable for connection of the CPU module and DOS/V personal
computer.
Refer to the GX Developer Operating Manual for details.
6 Drive unit –
(User-prepared)
Refer to the drive unit manual for details.
7
Connection cable
(for connection of
QD70 and drive unit)
–
(User-prepared)
Cable for connection of the QD70 and drive unit or mechanical system
input signals.
(To be fabricated in reference to the connected device manual and
Section 3.4.2)
2
