5 - 3 5 - 3
MELSEC-Q
5 SETUP AND PROCEDURES BEFORE OPERATION
5.2 Procedures before operation
This section gives the procedure up to the operation of the QD70.
Yes
No
No
Yes
Start
Module installation
Install the QD70 in the specified slot.
Wiring
Wire the external device to the QD70.
(Refer to Section 5.4.)
Intelligent function module switch setting
Make setting using GX Developer.
(Refer to Section 5.6.)
Connection confirmation
Confirm connection using GX Developer or
GX Configurator-PT. (Refer to Section 5.5.)
Drive unit operation confirmation
Make confirmation with a simple program in
the factory-set status. (Refer to Section 5.7.)
Do you use
GX Configurator-PT?
Initial setting
Using the FROM/TO instructions, create
an initial value write sequence program.
(Refer to Chapter 7.)
Programming, debugging
Create and confirm a sequence program.
(Refer to Chapter 7.)
System operation
Initial setting
Using GX Configurator-PT, make initial setting.
(Refer to Section 6.4.)
Do you make auto
refresh setting?
Auto refresh setting
Using GX Configurator-PT, make auto refresh
setting. (Refer to Section 6.5.)
