2 - 4 2 - 4
MELSEC-Q
2 SYSTEM CONFIGURATION
2.4 How to check the function version and the software version
The function version of the QD70 and the software version of the GX Configurator-PT
can be checked in the following methods.
[1] How to check the function version of the QD70
(a) Method using the rated plate on the module side face
Check the alphabet at the end of "SERIAL".
09021
SERIAL No. (The first five digits)
Function version
(b) Method using the peripheral device
Check the alphabet at the end of "Product information" displayed on
System monitor "Module's Detailed Information" of GX Developer.
[Operation of GX Developer]
Choose [Diagnostics] [System monitor] "QD70 module" and choose
Module's Detailed Information
.
<GX Developer display screen>
Function version
