4 - 29 4 - 29
MELSEC-Q
4 DATA USED FOR POSITIONING CONTROL
4.6.2 Module information monitor data
Item Storage details Default value
Storage buffer memory address
(Common for axis 1 to axis 8)
Md. 10
Error
status
At error occurrence, the bit corresponding to the
error occurrence axis turns ON.
0: Normal (OFF)
1: Error (ON)
(The error occurrence axis cannot be run)
When "
Cd. 1
Axis error reset" (axis control data)
of the corresponding axis is turned ON, the error
status of the corresponding axis is cleared (to
zero). (Refer to "Chapter 13" for details.)
b15 b0b4b8b12
0 : OFF
1 : ON
Not used
Storage item
Meaning
Axis 1 error
Axis 2 error
Axis 3 error
Axis 4 error
Axis 5 error
Axis 6 error
Axis 7 error
Axis 8 error
(For the QD70P4, b4 to b7 are "0" fixed.)
0000
H
1600
Md. 11
Warning
status
At warning occurrence, the bit corresponding to the
warning occurrence axis turns ON.
0: Normal (OFF)
1: Warning (ON)
When "
Cd. 1
Axis error reset" (axis control data)
of the corresponding axis is turned ON, the
warning status of the corresponding axis is cleared
(to zero). (Refer to "Chapter 13" for details.)
b15 b0b4b8b12
0 : OFF
1 : ON
Not used
Storage item
Meaning
Axis 1 warning
Axis 2 warning
Axis 3 warning
Axis 4 warning
Axis 5 warning
Axis 6 warning
Axis 7 warning
Axis 8 warning
(For the QD70P4, b4 to b7 are "0" fixed.)
0000
H
1601
