5 SETUP AND PROCEDURES BEFORE OPERATION
External device connection connector
The connectors for use with the QD70 should be purchased separately by the user.
The connector types and pressure displacement tool are listed below.
(a) Connector types
Type Model name
Soldering type, straight out A6CON1
Pressure displacement type, straight out A6CON2
(b) Pressure-displacement tool
Type Model name
Applicable
wire size
Supplier's office
Pressure-
displacement
tool
FCN-363T-
T005/H
AWG#24
•
FUJITSU AMERICA,INC.
250E Caribbean Drive Sunnyvale, CA 94089
U.S.A
Tel: (1-408)745-4900
•
FUJITSU EUROPE B.V.
Jupiterstaat 13-15, our 2132 Hoofddorp, The
Netherland
Tel: (31)23-5560910
•
FUJITSU EUROPE B.V. Zweiniederlassung
Deutschland
Schatzbogen 86 D-81829 Munchen
Germany
Tel: (49)89-42742320
•
FUJITSU EUROPE (UK)
Network House, Morres Drive, Maidenhead,
Berkshire, SL6 4FH United Kingdom
Tel: (44)1628-504600
•
FUJITSU EUROPE B.V.
127 Chemin Des Bassins, Europarc, Cleteril
94035 Cleterll 94035 France
Tel: (33)145139940
•
FUJITSU ASIA PACIFIC PTE LIMITED
102E Pasir Panjang Road, #04-01 Citilink
Warehouse Complex, Singapore 118529
Tel: (65)375-8560
•
FUJITSU HONG KONG CO., LTD.
Suite 913 Ocean Centre, 5 Canton Road,
TST, Kowloon, Hong Kong
Tel: (852)2881-8495
